Last month the New York Times ran a story about a sculpture based on cutting open a “Menger sponge,” a shape formed by recursively cutting holes through a cube. All the holes are rectangular, but when you cut the sponge open at an angle, you see six-pointed stars.

Here are some better photos, including both a physical model and a computer animation. Thanks to Mike Croucher for the link.

I’ve written some Python code to take slices of a Menger sponge. Here’s a sample output.

The Menger sponge starts with a unit cube, i.e. all coordinates are between 0 and 1. At the bottom of the code, you specify a plane by giving a point inside the cube and vector normal to the plane. The picture above is a slice that goes through the center of the cube (0.5, 0.5, 0.5) with a normal vector running from the origin to the opposite corner (1, 1, 1).

from math import floor, sqrt
from numpy import empty, array
from matplotlib.pylab import imshow, cm, show
def outside_unit_cube(triple):
x, y, z = triple
if x < 0 or y < 0 or z < 0:
return 1
if x > 1 or y > 1 or z > 1:
return 1
return 0
def in_sponge( triple, level ):
"""Determine whether a point lies inside the Menger sponge
after the number of iterations given by 'level.' """
x, y, z = triple
if outside_unit_cube(triple):
return 0
if x == 1 or y == 1 or z == 1:
return 1
for i in range(level):
x *= 3
y *= 3
z *= 3
# A point is removed if two of its coordinates
# lie in middle thirds.
count = 0
if int(floor(x)) % 3 == 1:
count += 1
if int(floor(y)) % 3 == 1:
count += 1
if int(floor(z)) % 3 == 1:
count += 1
if count >= 2:
return 0
return 1
def cross_product(v, w):
v1, v2, v3 = v
w1, w2, w3 = w
return (v2*w3 - v3*w2, v3*w1 - v1*w3, v1*w2 - v2*w1)
def length(v):
"Euclidean length"
x, y, z = v
return sqrt(x*x + y*y + z*z)
def plot_slice(normal, point, level, n):
"""Plot a slice through the Menger sponge by
a plane containing the specified point and having
the specified normal vector. The view is from
the direction normal to the given plane."""
# t is an arbitrary point
# not parallel to the normal direction.
nx, ny, nz = normal
if nx != 0:
t = (0, 1, 1)
elif ny != 0:
t = (1, 0, 1)
else:
t = (1, 1, 0)
# Use cross product to find vector orthogonal to normal
cross = cross_product(normal, t)
v = array(cross) / length(cross)
# Use cross product to find vector orthogonal
# to both v and the normal vector.
cross = cross_product(normal, v)
w = array(cross) / length(cross)
m = empty( (n, n), dtype=int )
h = 1.0 / (n - 1)
k = 2.0*sqrt(3.0)
for x in range(n):
for y in range(n):
pt = point + (h*x - 0.5)*k*v + (h*y - 0.5)*k*w
m[x, y] = 1 - in_sponge(pt, level)
imshow(m, cmap=cm.gray)
show()
# Specify the normal vector of the plane
# cutting through the cube.
normal = (1, 1, 0.5)
# Specify a point on the plane.
point = (0.5, 0.5, 0.5)
level = 3
n = 500
plot_slice(normal, point, level, n)
